As an industry leader in the specialty wire segment, Mount Joy Wire Corporation manufactures an assortment of brush wire that provides North American brush manufacturers maximum performance. Mount Joy Wire adds value to our quality products with a proven track record, technical expertise, support, and versatility. Brush wire types include high and low carbon, regular tempered, high fatigue, scratch, untempered steel, brass plated and stainless steel.
Products
- Tempered High Fatigue
- Bright / Black Tempered
- Scratch
- Untempered/Improved Tiger Claw
- Stainless Steel
- Brass Plated
- Flat Tempered
- Annealed, Plated, and/or Patented Winding Wires
Put Ups
- Straight Single Strand (Coil or Spool)
- Straight Bunched Multi-Strand
- Straight In Hanks
- Crimped In Coils
- Crimped In Hank
- Crimped Multi-Strand
- Pin Crimped in Coils
- Pin Crimped in Hanks
Sizes
- Carbon Brush: .0025″ – .035″
- Stainless Brush: .005″ – .023″
- Winding Wires: Made to customer specifications
- Flat Tempered: Up To .125″ Wide
Packaging
Type |
Capacity |
Head |
Traverse |
Barrel Diameter |
Arbor Hole |
TareWeight |
50# Masonite Spool | 40-70# | 10″ | 6″ | 4-1/2″ | 1-1/4″ | 3# |
80# Metal Spool | 60-80# | 12″ | 6″ | 6″ | 1-1/4″ | 6-1/2# |
50# Metal Spool | 40-60# | 10″ | 6″ | 4-1/2″ | 1-1/4″ or 5/8″ |
4# |
12×12 Notched Cardboard Core |
50-80# | – | 12″ | 11-3/4″ | 11-1/4″ | 2# |
14″ Core |
100-180# | – | 11″ | 14-1/2″ | 14″ | 3-1/4″ |
10″ Core | 20-50# | – | 7″ | 10-1/2″ | 10″ | 1-1/4″ |
9-1/4″ Core |
20-40# | – | 6″ | 9-1/2″ | 9-1/4″ | 1# |
20″ Plywood Spool | 50-80# | 20″ | 12″ | 11-3/4″ | 1-1/4″ | 7# |
